Paged Form

Thick-ply softwood plywood, faced with specialised resin-impregnated paper.

  • Declaration of Performance CE
  • CARB-EPA certificate
  • EPD
  • PEFC
  • FSC

Thick-ply softwood plywood with an exterior-grade glue bond, faced with specialised, highly durable resin-impregnated paper.

More about the productPaged Form is a water-resistant formwork plywood designed for contractors looking for a durable and economical solution for building concrete structures. The product was developed for everyday work on construction sites, where reliability, a good-quality concrete surface and the ability to reuse formwork panels many times are what count.

Paged Form is a water-resistant formwork plywood designed for contractors looking for a durable and economical solution for building concrete structures. The product was developed for everyday work on construction sites, where reliability, a good-quality concrete surface and the ability to reuse formwork panels many times are what count.

For contractors, this means lower spending on formwork materials and the ability to use a single product across a wide range of construction work. For precast concrete manufacturers, it is a solution that ensures a consistent surface quality of the elements and stable performance over successive production cycles.

Thanks to its favourable price-to-durability ratio, Paged Form is a versatile solution for residential projects as well as for industrial and commercial buildings.

Paged Form plies are made of 2.5 mm and 3.2 mm thick pine veneers. The greater-than-standard thickness of the softwood plies keeps the product lightweight. At the same time, the plywood maintains high mechanical strength.

Product constructionPaged Form is a multi-ply softwood plywood with a cross-banded veneer lay-up and an exterior-grade glue bond. The panel surface is protected by impregnated kraft paper coated with phenolic resin, which provides a smooth working surface and resistance to the conditions that occur during concreting.
Paged Form - cross-section of the formwork panel showing the pine plies

Paged Form is a multi-ply softwood plywood with a cross-banded veneer lay-up and an exterior-grade glue bond. The panel surface is protected by impregnated kraft paper coated with phenolic resin, which provides a smooth working surface and resistance to the conditions that occur during concreting.

The combination of a softwood construction and a phenolic face provides the rigidity, durability and consistent performance required in formwork systems. The product can be edge-machined, cut to size and further processed to meet project requirements.

Technical parameters, features and propertiesThe key feature of Paged Form is that it can be reused many times while maintaining the quality of the concrete surface. The phenolic face creates a smooth working surface that reduces the adhesion of the concrete mix and makes it easier to clean the panels between successive pours.
Paged Form - close-up of the resin-impregnated paper surface

The key feature of Paged Form is that it can be reused many times while maintaining the quality of the concrete surface. The phenolic face creates a smooth working surface that reduces the adhesion of the concrete mix and makes it easier to clean the panels between successive pours.

The plywood construction provides the bending resistance and load-bearing capacity required for vertical and horizontal formwork. The exterior-grade glue bond increases the durability of the product and allows it to be used in demanding construction site conditions.

Compared with single-use panels or alternative materials, Paged Form significantly reduces the cost of the formwork facing, thanks to its reusability and easy handling on site.

Advantages and applications

Advantages

  • Dimensional stability
  • Lighter construction
  • Ecological manufacturing process
  • Wear resistance
  • Moisture resistance

Industries and applications

  • Construction
  • Formwork systems
  • Formwork
Applications and benefits

Residential construction

Paged Form is used for foundations, walls, columns, beams and floor slabs in single-family and multi-family housing. The product allows formwork to be set up quickly and delivers a consistent quality of concrete surfaces.

Commercial and industrial construction

In office, warehouse and industrial buildings, Paged Form performs well as an economical plywood for standard formwork systems. Its high durability allows the material to be used efficiently through successive phases of the project.

Precast concrete

The product is used in the production of precast elements that require a good concrete surface quality and consistent production parameters. The smooth formwork surface reduces the amount of finishing work after demoulding.

Technical data
Standard formats [mm]
2500 × 12502440 × 1220
Thicknesses [mm]
1215182124273035
Average density [kg/m³] 550-650
Bonding quality class [EN 314-2] 3
Formaldehyde emission class [EN 717-1] E1
Reaction to fire class* [EN 13501-1] D-s2, d0
Declaration of Performance (DoP) Structural plywood; CE2+
Type of face Paper impregnated with specialised phenolic resin
Base weight 390 g/m²
Colour Light brown
Taber test [EN 438-2] 850
Number of cycles (uses)** 5-10

IMPORTANT! If the product is cut into smaller formats or otherwise modified, the edges must be re-sealed.

*without an air gap, for thicknesses of 9 mm and above

**the estimated number of uses of the formwork plywood is indicative only; the actual number of reuses depends on factors related to how the plywood is used and handled

Custom-made product

Custom panel constructions available on request.
